SHOP by U-JOINT SIZE

Click on the various Series in Chart below for more info about each one

Series	See More Info	LockUp Width	Bearing Cap Diameter	LockUp Type
1000	MORE INFO	1.5 x 1.5	.938	INSIDE C CLIP
1100/1110	MORE INFO	1.718 x 1.718	1.00	INSIDE C CLIP
1100/1110	MORE INFO	2.411 x 2.411	.938	Outside Snap Ring
1210	MORE INFO	2.438 x 2.438	1.062	Outside Snap Ring
1310	MORE INFO	3.219 x 3.219	1.062	Outside Snap Ring
1310 Ford	MORE INFO	3.219 x 3.219	(2) 1.062 and (2) 1.125	Outside Snap Ring
1330	MORE INFO	3.625 x 3.625	1.062	Outside Snap Ring
1330 Ford	MORE INFO	3.625 x 3.625	(2) 1.062 and (2) 1.125	Outside Snap Ring
1350	MORE INFO	3.625 x 3.625	1.188	Outside Snap Ring
1355 AAM	MORE INFO	3.622 x 3.622	1.188	Outside Snap Ring
1410	MORE INFO	4.188 x 4.188	1.188	Outside Snap Ring
1415 AAM	MORE INFO	4.181 x 4.181	1.188	Outside Snap Ring
1480	MORE INFO	4.188 x 4.188	1.375	Outside Snap Ring
1485 AAM	MORE INFO	4.181 x 4.181	1.375	Outside - Inside
1550	MORE INFO	4.964 x 4.964	1.375	Outside Snap Ring
1555 AAM	MORE INFO	4.965 x 4.965	1.375	Outside - Inside
7260 Dodge	MORE INFO	2.125 x 2.125	1.078	INSIDE C CLIP
7290 Dodge	MORE INFO	2.625 x 2.625	1.125	INSIDE C CLIP
5380 Dodge	MORE INFO	3.0 x 3.0	1.231	INSIDE C CLIP
3R Dodge	MORE INFO	2.556 x 2.556	1.125	INSIDE C CLIP
3R GM	MORE INFO	2.556 x 2.556	1.125	INSIDE C CLIP
2R series	MORE INFO	2.344 x 2.344	1.000	INSIDE C CLIP
2RL series	MORE INFO	2.337 x 2.334	1.000	INSIDE C CLIP

U-Joints BY SIZE

1000 Series U-Joint 1.500 x 1.500 - .938 inch caps inside c clips

	DANA SPICER 5-103X Universal Joint 1000 Series CLICK HERE for More Details Part Number: 5-103X	$20.96	IN STOCK

	DANA SPICER 5-170X PTO Universal Joint 1000 Series for Power Take Off CLICK HERE for More Details Part Number: 5-170X	$17.95	SOLD OUT

	NEAPCO 1-0170 - PTO Universal Joint 1000 Series for Power Take Off CLICK HERE for More Details Part Number: 1-0170	$17.29	IN STOCK

1100/1110 Series U-Joint 1.718 x 1.718 - 1 inch caps inside c clips

	Neapco 1-0105 Universal Joint 1110 Series Genuine Neapco CLICK HERE for More Details Part Number: 1-0105	$32.50

	DANA SPICER 5-105X universal joint 1.718 x 1.718 - 1 inch caps INSIDE Clips CLICK HERE for More Details Part Number: 5-105X	$35.95	IN STOCK

1100/1110 Series U-Joint 2.411 x 2.411 - .938 inch caps outside snap rings

	DANA SPICER 5-101X PTO Universal Joint 1100 Series for Power Take Off CLICK HERE for More Details Part Number: 5-101X	$23.84	IN STOCK

1210 Series U-Joint 2.438 x 2.438 - 1.062 outside snap ring

1.062 X 1.062 Bearing Cap Diameter

	DANA SPICER 5-443X Rear Driveshaft Universal Joint 1984 to 1986 Ford Bronco II CLICK HERE for More Details Part Number: 5-443X	$19.95	SOLD OUT

	NEAPCO 1-0443 Rear Driveshaft Universal Joint 1984 to 1986 Ford Bronco II CLICK HERE for More Details Part Number: 1-0443	$23.95	IN STOCK

1310 Series U-Joint 3.219 X 3.219 - 1.062 - 1.125 outside snap ring

1.062 X 1.062 Bearing Cap Diameter

	Dana Spicer 5-153X Universal Joint Greaseable 1310 series 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 5-153X	$13.10	IN STOCK

	Dana Spicer 5-1310-1X Universal Joint 1310 Series GREASEABLE 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 5-1310-1X	$26.95	IN STOCK

	Dana Spicer 5-1310X Universal Joint 1310 Series NON Greaseable 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 5-1310X	$19.66	IN STOCK

	Dana Spicer 5-3613X Universal Joint 1310 Series COATED for ALUMINUM DRIVESHAFTS 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 5-3613X	$22.30	IN STOCK

	Neapco 1-0153 Greaseable universal joint 1310 series 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 1-0153	$16.59	IN STOCK

	Neapco 1-0153G NON Greaseable universal joint 1310 series 3.219 x 1.062 outside snap rings CLICK HERE for More Details Part Number: 1-0153G	$20.26	IN STOCK

1.062 X 1.125 Bearing Cap Diameter

	Neapco 1-4635 Universal Joint greaseable fits FORD 8 inch or 9 inch rear has (2) 1.125 inch caps to fit pinion yoke saddle also called Ford Big Cap u-joint CLICK HERE for More Details Part Number: 1-4635	~~$36.33~~ $34.60

	Dana Spicer 5-7439X Non Greaseable Universal Joint fits FORD 8 inch or 9 inch rear has (2) 1.125 inch caps to fit pinion yoke saddle also called Ford Big Cap u-joint CLICK HERE for More Details Part Number: 5-7439X	$22.45	IN STOCK

1330 Series U-Joint 3.625 X 3.625 - 1.062 - 1.125 outside snap ring

1.062 X 1.062 Bearing Cap Diameter

	NEAPCO 2-4800 - 1330 Series Greaseable Universal Joint CLICK HERE for More Details Part Number: 2-4800	$19.80	IN STOCK

	Neapco 2-4800G Non Greaseable Universal Joint 1330 Series 3.625 in. x 1.062 in. CLICK HERE for More Details Part Number: 2-4800G	$20.95	IN STOCK

	Dana Spicer 5-1330-1X GREASEABLE Universal Joint 1330 Series CLICK HERE for More Details Part Number: 5-1330-1X	$20.43	IN STOCK

	Dana Spicer 5-213X Universal Joint 1330 Series Greaseable U-Joint CLICK HERE for More Details Part Number: 5-213X	$19.19	IN STOCK

	DANA SPICER 5-1330X - Universal Joint 1330 Series with (4) 1.062 Bearing Caps NON Greaseable CLICK HERE for More Details Part Number: 5-1330X	$20.77	IN STOCK

	DANA SPICER 5-3614X Universal Joint 1330 Series COATED for ALUMINUM DRIVESHAFTS CLICK HERE for More Details Part Number: 5-3614X	$23.90	IN STOCK

1.062 X 1.125 Bearing Cap Diameter

	Neapco 2-4900 Greaseable Universal Joint 1330 series fits Ford with 1.125 caps CLICK HERE for More Details Part Number: 2-4900	$24.95	IN STOCK

	DANA SPICER 5-1204X - Universal Joint 1330 Series FORD with (2) 1.125 Bearing Caps Greaseable CLICK HERE for More Details Part Number: 5-1204X	$19.38	IN STOCK

	DANA SPICER 5-7438X Universal Joint 1330 Series FORD with (2) 1.125 Bearing Caps NON Greaseable CLICK HERE for More Details Part Number: 5-7438X	$28.95	IN STOCK

1350 Series U-Joint 3.625 X 3.625 - 1.188 outside snap ring

1.188 X 1.188 Bearing Cap Diameter

	Neapco 2-0053G universal joint 1350 Series non greaseable 3.622 x 1.188 CLICK HERE for More Details Part Number: 2-0053G	$27.95	IN STOCK

	Dana Spicer 5-1350-1X GREASEABLE Universal Joint 1350 Series fitting in end of bearing cap CLICK HERE for More Details Part Number: 5-1350-1X	$32.60	IN STOCK

	Dana Spicer 5-178X Greaseable u-joint 1350 Series CLICK HERE for More Details Part Number: 5-178X	$20.95	IN STOCK

	Dana Spicer 5-1350XP Plus Series upgraded 1350 solid body universal joint CLICK HERE for More Details Part Number: 5-1350XP	$27.60	IN STOCK

	Dana Spicer 5-1350X Universal Joint NON Greaseable 1350 series cold forged solid body heat treated precision ground and case hardened with multi lip seals CLICK HERE for More Details Part Number: 5-1350X	$23.54	IN STOCK

	DANA SPICER 5-3615X Universal Joint 1350 Series COATED for ALUMINUM DRIVESHAFTS CLICK HERE for More Details Part Number: 5-3615X	$37.25	IN STOCK

1355 Series AAM U-Joint 3.622 X 3.622 - 1.188 outside snap ring

1.188 X 1.188 Bearing Cap Diameter

	AAM 19256728 Universal Joint for AAM Front CV Driveshaft 1355 series DODGE 2500 and 3500 (40085102), (7064399) CLICK HERE for More Details Part Number: 19256728	$36.95	IN STOCK

	Dana Spicer 5-3208X UNIVERSAL JOINT for AAM Driveshaft 1355 series U-Joint CLICK HERE for More Details Part Number: 5-3208X	~~$35.67~~ $33.55

1410 Series U-Joint 4.188 X 4.188 - 1.188 outside snap ring

1.188 X 1.188 Bearing Cap Diameter

	Dana Spicer 5-160X Universal Joint 1410 Series CLICK HERE for More Details Part Number: 5-160X	$24.95	IN STOCK

	Dana Spicer 5-1410-1X GREASEABLE Universal Joint 1410 Series fitting in end of bearing cap CLICK HERE for More Details Part Number: 5-1410-1X	$36.24	IN STOCK

	Dana Spicer 5-1410X Universal Joint 1410 Series NON Greaseable CLICK HERE for More Details Part Number: 5-1410X	$31.95	IN STOCK

	DANA SPICER 5-3616X Universal Joint 1410 Series COATED for ALUMINUM DRIVESHAFTS CLICK HERE for More Details Part Number: 5-3616X	$33.74	IN STOCK

	Neapco 2-0054G NON Greaseable universal joint 1410 series 4.188 x 1.188 outside snap rings CLICK HERE for More Details Part Number: 2-0054G	$31.85

1415 Series AAM U-Joint 4.181 X 4.181 - 1.188 outside snap ring

1.188 X 1.188 Bearing Cap Diameter

	Dana Spicer 5-3207X UNIVERSAL JOINT for AAM Driveshaft 1415 series U-Joint CLICK HERE for More Details Part Number: 5-3207X	$39.69

	AAM 74085339 Universal Joint AAM 1415 series U-Joint DODGE (7064389) CLICK HERE for More Details Part Number: 74085339	$43.95	IN STOCK

1480 Series U-Joint 4.188 X 4.188 - 1.375 outside snap ring

1.375 X 1.375 Bearing Cap Diameter

	Dana Spicer 5-188X UNIVERSAL JOINT 1480 series Greaseable U-joint CLICK HERE for More Details Part Number: 5-188X	$29.25	IN STOCK

	Dana Spicer SPL55X Universal Joint 1480 series NON Greaseable u-joint CLICK HERE for More Details Part Number: SPL55X	$40.94	IN STOCK

1485 Series AAM U-Joint 4.181 X 4.181 - 1.375 outside snap ring

1.375 X 1.375 Bearing Cap Diameter

	AAM 74081485 Universal Joint 1485 series fits DODGE AAM Rear Driveshaft and 9.25 Front Axles CLICK HERE for More Details Part Number: 74081485	$62.95	IN STOCK

	AAM 74110001 WHEEL JOINT KIT- Fits 2003 to 2009 DODGE RAM 2500/3500 with 9.25 Front Axles 1485 series CLICK HERE for More Details Part Number: 74110001	$144.95	IN STOCK FREE SHIPPING

	Dana Spicer 5-3206X UNIVERSAL JOINT for AAM Driveshaft 1485 series U-Joint CLICK HERE for More Details Part Number: 5-3206X	~~$72.07~~ $60.71	FACTORY DIRECT

1550 Series U-Joint 4.964 X 4.964 - 1.375 outside snap ring

1.375 X 1.375 Bearing Cap Diameter

	Dana Spicer 5-155X Universal Joint 1550 Series Greaseable CLICK HERE for More Details Part Number: 5-155X	$45.95	SOLD OUT

	Dana Spicer SPL70-1X Universal Joint 1550 Series GREASEABLE CLICK HERE for More Details Part Number: SPL70-1X	$59.88	IN STOCK

	Dana Spicer SPL70X Universal Joint 1550 Series Non Greaseable CLICK HERE for More Details Part Number: SPL70X	$56.95	IN STOCK

1555 Series AAM U-Joint 4.965 X 4.965 - 1.375 outside snap ring

1.375 X 1.375 Bearing Cap Diameter

	AAM 74081555 Driveshaft Universal Joint 1555 series fits DODGE 2500/3500 AAM Rear Driveshaft with Outside Snap Rings CLICK HERE for More Details Part Number: 74081555	$63.95	IN STOCK

	AAM 74110002 WHEEL JOINT KIT - Fits 2010 to 2013 DODGE RAM 2500/3500 with 9.25 Front Axles 1555 series CLICK HERE for More Details Part Number: 74110002	$150.95	IN STOCK FREE SHIPPING

2RL Series U-Joint 2.337 x 2.337 - 1.00 inch caps inside c clips

	Dana Spicer 5-3263X Universal Joint 2RL series 2.337 x 2.337 with 1.000 caps Inside c-clips CLICK HERE for More Details Part Number: 5-3263X	$38.39	IN STOCK

2R Series U-Joint 2.344 x 2.344 - 1.00 inch caps inside c clips

	11-60661 Universal Joint 2R series 2.342 x 2.342 - 1.00 inch cap diameter INSIDE C-Clips CLICK HERE for More Details Part Number: 11-60661	$26.95	IN STOCK

3R Series U-Joint 2.562 X 2.562 - 1.125 inside c clips

1.125 X 1.125 Bearing Cap Diameter

	AAM 12479126 Universal Joint 3R Series with Inside C-Clips CLICK HERE for More Details Part Number: 12479126	$35.95	IN STOCK

	SPICER 5-3147X 3R Series U-joint Greaseable CLICK HERE for More Details Part Number: 5-3147X	$19.25	IN STOCK

	Dana Spicer 5-795X Universal Joint 3R Series Non greaseable CLICK HERE for More Details Part Number: 5-795X	$27.95	IN STOCK

Dodge 7260 Series U-Joint 2.125 X 2.125 - 1.078 inside c clip

1.078 X 1.078 Bearing Cap Diameter

	Dana Spicer 5-1306X Universal Joint 7260 Series with Grease fitting in BODY - Obsolete no longer available CLICK HERE for More Details Part Number: 5-1306X	$15.35

	Dana Spicer 5-3228X U-Joint 7260 series Grease fitting in cap CLICK HERE for More Details Part Number: 5-3228X	$29.95	IN STOCK

	NEAPCO 1-6300 Universal joint DODGE 7260 Series with Grease fitting in BEARING CAP CLICK HERE for More Details Part Number: 1-6300	$28.55	IN STOCK

	NEAPCO 1-6301 Universal joint DODGE 7260 Series with Grease fitting in BODY CLICK HERE for More Details Part Number: 1-6301	$30.35	IN STOCK

Dodge 7290 Series U-Joint 2.625 X 2.625 - 1.125 inside c clip

1.125 X 1.125 Bearing Cap Diameter

	Dana Spicer 5-1309X Greaseable Universal Joint 7290 series Dodge, Plymouth, Chrysler, Mopar INSIDE CLIPS CLICK HERE for More Details Part Number: 5-1309X	$21.70	IN STOCK

	Dana Spicer 5-811X Universal Joint NON Greaseable 7290 series DODGE, Plymouth, Chrysler, Mopar INSIDE CLIPS CLICK HERE for More Details Part Number: 5-811X	$19.55	IN STOCK

Detroit 5380 Series U-Joint 3 X 3 - 1.231 inside c clip

1.231 X 1.231 Bearing Cap Diameter

	Dana Spicer 5-1301X Universal Joint Greaseable Detroit 5380 series early DODGE W350 truck and motorhome chassis INSIDE CLIPS CLICK HERE for More Details Part Number: 5-1301X	$52.95	IN STOCK
