3.5 x .083 DOM DRIVESHAFT TUBING - 12 INCH LENGTH
$25.30 each
|
| Part Number:
3500-083-12
|
$25.30 each
|
|
DRIVESHAFT TUBING - DOM
- 3.5 INCH OUTSIDE DIAMETER (3 1/2 inch)
- .083 WALL THICKNESS
- DOM - Drawn over mandrel
- ASTM A513
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
3.5 x .083 DOM DRIVESHAFT TUBING - 24 INCH LENGTH
$50.60 each
|
| Part Number:
3500-083-24
|
$50.60 each
|
|
DRIVESHAFT TUBING - DOM
- 3.5 INCH OUTSIDE DIAMETER (3 1/2 inch)
- .083 WALL THICKNESS
- DOM - Drawn over mandrel
- ASTM A513
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
3.5 x .083 DOM DRIVESHAFT TUBING - 36 INCH LENGTH
$79.20 each
|
| Part Number:
3500-083-36
|
$79.20 each
|
|
DRIVESHAFT TUBING - DOM
- 3.5 INCH OUTSIDE DIAMETER (3 1/2 inch)
- .083 WALL THICKNESS
- DOM - Drawn over mandrel
- ASTM A513
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
3.5 x .083 DOM DRIVESHAFT TUBING - 48 INCH LENGTH
$107.80 each
|
| Part Number:
3500-083-48
|
$107.80 each
|
|
DRIVESHAFT TUBING - DOM
- 3.5 INCH OUTSIDE DIAMETER (3 1/2 inch)
- .083 WALL THICKNESS
- DOM - Drawn over mandrel
- ASTM A513
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
3.5 x .083 DOM DRIVESHAFT TUBING - 60 INCH LENGTH
$137.50 each
|
| Part Number:
3500-083-60
|
$137.50 each
|
|
DRIVESHAFT TUBING - DOM
- 3.5 INCH OUTSIDE DIAMETER (3 1/2 inch)
- .083 WALL THICKNESS
- DOM - Drawn over mandrel
- ASTM A513
|
|
Status: IN STOCK - FREE SHIPPING
|
|
|
|
|
DANA SPICER 3-28-537 Weld Yoke 1480 Series to fit 3.5 inch .083 wall tube
$36.95 $32.95 each
|
| Part Number:
3-28-537
|
$36.95 $32.95 each
|
|
DANA SPICER 3-28-537
1480 Series Weld Yoke
|
|
Status: IN STOCK
|
|
|
|
|
DANA SPICER 3-28-547 Weld Yoke 1480 Series to fit 3.5 inch .083 wall tube - 35 degree joint angle
$48.95 $43.95 each
|
| Part Number:
3-28-547
|
$48.95 $43.95 each
|
|
DANA SPICER 3-28-547
1480 Series Weld Yoke
- Fits 3.5 inch OD X .083 wall tubing
- F - Butt Diameter = 3.345
- Series = 1480
- Lock up style = OUTSIDE SNAP RING
- E - Universal Joint Width = 4.187
- D - Universal Joint Bore = 1.375
- H - Center of u-joint bore to point of weld = 2.312
- This yoke has a 35 degree joint angle
- Special Notes: USE KIT 5-188X, SPL55X
|
|
Status: IN STOCK
|
|
|
|
|
Dana Spicer SPL55X Universal Joint 1480 series NON Greaseable u-joint
$40.94 each
|
| Part Number:
SPL55X
|
$40.94 each
|
|
DANA SPICER SPL55X
1480 Series NON Greaseable U-Joint
- NON Greaseable Universal Joint
- Dimensions
- Dimension A & B = 4.188 inches wide in both directions
- Dimension C & D = All 4 bearing caps are 1.375 inch diameter
- Outside snap rings
|
|
Status: IN STOCK
|
|
|
|
|
Dana Spicer 5-188X UNIVERSAL JOINT 1480 series Greaseable U-joint
$29.25 each
|
| Part Number:
5-188X
|
$29.25 each
|
|
DANA SPICER 5-188X
1480 Series GREASEABLE U-Joint
- Greaseable Universal Joint
- Dimensions
- Dimension A & B = 4.188 inches wide in both directions
- Dimension C & D = All 4 bearing caps are 1.375 inch diameter
- Outside snap rings
|
|
Status: IN STOCK
|
|
|
