Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end Strap and Bolt style
$88.95 each
|
| Part Number:
3-4-8691-1X
|
$88.95 each
|
|
Dana Spicer 3-4-8691-1X
PINION YOKE
- 1350 series
- Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
- 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
- DOES NOT FIT 14 bolt Full Floater with bolt in axles
- DOES NOT have a dust shield
- Use with seal part number 3896 ... see bottom of this page
DIMENSIONS
- 1350 series
- 30 SPLINE
- SPLINE OD = 1.312
- D = 1.188
- E = 3.625
- Q = 1.156
- R = 1.938
- S = 3.125
|
|
Status: IN STOCK
|
|
