DANA SPICER 2-2-02768 Flange Yoke 1330 Series
Part Number:
2-2-02768


UPC:
023913238926
Your Cost $55.71 Sale Price $46.93
You Save $8.78
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 2-2-02768

1330 Series Flange Yoke




Spicer
DANA SPICER 2-2-02768 Flange Yoke 1330 Series
DANA SPICER 2-2-02768 Flange Yoke 1330 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $55.71 Sale Price $46.93
You Save $8.78

DANA SPICER 2-2-02768

1330Series Flange Yoke

  • A - Flange or Swing Diameter = 5.118 inches
  • B - Bolt Circle Diameter = 3.674 inches
    • Bolt Hole Diameter = 0.482 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 1.811 inches
    • Center Pilot = MALE
  • Series = 1330
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.653 inches
  • X - inches
  • Y - inches
  • Special Notes: Bolts holes are equally spaced





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 2-2-02768 Flange Yoke 1330 Series

DANA SPICER 2-2-02768 Flange Yoke 1330 Series
