DANA SPICER 2-2-1209 Flange Yoke 1330 Series
|
|
Your Cost
$104.63 Sale Price $88.14You Save $16.49
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 2-2-1209
1330 Series Flange Yoke
UPC: 023913236113
Part Number: 2-2-1209
|
DANA SPICER 2-2-1209 Flange Yoke 1330 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$104.63 Sale Price $88.14You Save $16.49
|
DANA SPICER 2-2-1209
1330Series Flange Yoke
- A - Flange or Swing Diameter = 4.625 inches
- B - Bolt Circle Diameter = 3.750 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 2.750 inches
- Series = 1330
- Outside Snap Ring Style
- U-Joint Width between snap rings = 3.625 inches
- D - U-Joint Bearing cap diameter = 1.062 inches
- G - Center of u-joint bore to Face of flange = 1.562 inches
- X - inches
- Y - inches
- Special Notes:
|
|
DANA SPICER 2-2-1209 Flange Yoke 1330 Series
|
|
