DANA SPICER 2-2-1989 Flange Yoke 1310 Series
Part Number:
2-2-1989


UPC:
023913236267
Your Cost $54.53 Sale Price $45.67
You Save $8.86
STATUS:  IN STOCK

DANA SPICER 2-2-1989

1310 Series Flange Yoke




Spicer
DANA SPICER 2-2-1989 Flange Yoke 1310 Series
DANA SPICER 2-2-1989 Flange Yoke 1310 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $54.53 Sale Price $45.67
You Save $8.86

DANA SPICER 2-2-1989

1310Series Flange Yoke

  • A - Flange or Swing Diameter = 4.906 inches
  • B - Bolt Circle Diameter = 3.937 inches
    • Bolt Hole Diameter = 0.489 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.162 inches
    • Center Pilot = FEMALE
  • Series = 1310
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.219 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.930 inches
  • X - 2.780 inches
  • Y - 2.780 inches
  • Special Notes: BOLT HOLES ARE EQUALLU SPACED. PART HAS HOLE THRU CENTER





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 2-2-1989 Flange Yoke 1310 Series

DANA SPICER 2-2-1989 Flange Yoke 1310 Series
