DANA SPICER 2-2-2029 Flange Yoke 1310 Series
|
|
Your Cost
$73.55 Sale Price $68.50You Save $5.05
STATUS:
IN STOCK
|
|
DANA SPICER 2-2-2029
1310 Series Flange Yoke
UPC: 023913237592
Part Number: 2-2-2029
|
DANA SPICER 2-2-2029 Flange Yoke 1310 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: IN STOCK
YOUR COST:
$73.55 Sale Price $68.50You Save $5.05
|
DANA SPICER 2-2-2029
1310Series Flange Yoke
- A - Flange or Swing Diameter = 4.740 inches
- B - Bolt Circle Diameter = 3.740 inches
- Bolt Hole Diameter = 0.478 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 1.964 inches
- Series = 1310
- Outside Snap Ring Style
- U-Joint Width between snap rings = 3.219 inches
- D - U-Joint Bearing cap diameter = 1.062 inches
- G - Center of u-joint bore to Face of flange = 1.780 inches
- X - inches
- Y - inches
- Special Notes: BOLT HOLES ARE EQUALLY SPACED
|
|
DANA SPICER 2-2-2029 Flange Yoke 1310 Series
|
|
