DANA SPICER 2-2-489 Flange Yoke 1330 Series
Part Number:
2-2-489


UPC:
023913235550
Your Cost $39.70 Sale Price $36.95
You Save $2.75
STATUS:  IN STOCK

DANA SPICER 2-2-489

1330Series Flange Yoke

  • A - Flange or Swing Diameter = 4.625 inches
  • B - Bolt Circle Diameter = 3.750 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.750 inches
    • Center Pilot = MALE
  • Series = 1330
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.562 inches
  • X - inches = 2.875
  • Y - inches = 2.410
  • Special Notes: This DOES NOT FIT any Toyota applications
Spicer
DANA SPICER 2-2-489 Flange Yoke 1330 Series
DANA SPICER 2-2-489 Flange Yoke 1330 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $39.70 Sale Price $36.95
You Save $2.75

DANA SPICER 2-2-489

1330Series Flange Yoke

  • A - Flange or Swing Diameter = 4.625 inches
  • B - Bolt Circle Diameter = 3.750 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.750 inches
    • Center Pilot = MALE
  • Series = 1330
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.562 inches
  • X - inches = 2.875
  • Y - inches = 2.410
  • Special Notes: This DOES NOT FIT any Toyota applications





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 2-2-489 Flange Yoke 1330 Series

DANA SPICER 2-2-489 Flange Yoke 1330 Series
