DANA SPICER 3-2-489 Flange Yoke 1480 Series
Part Number:
3-2-489


UPC:
023913215767
Your Cost $84.58 Sale Price $71.95
You Save $12.63
STATUS:  IN STOCK

DANA SPICER 3-2-489

  • 1480 Series Flange Yoke





Spicer
DANA SPICER 3-2-489 Flange Yoke 1480 Series
DANA SPICER 3-2-489 Flange Yoke 1480 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $84.58 Sale Price $71.95
You Save $12.63

DANA SPICER 3-2-489

  • 1480 Series Flange Yoke

Dimensions

  • A - Flange or Swing Diameter = 5.875 inches
  • B - Bolt Circle Diameter = 4.750 inches
    • Bolt Hole Diameter = 0.500 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.750 inches
    • Center Pilot = MALE
  • Series = 1480
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.187 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 1.500 inches
  • X - inches = 3.053
  • Y - inches = 3.639
  • Special Notes:

 CLICK HERE : For ALL DANA SPICER Flange Yoke Part Numbers, Specifications and Dimensions



Denny's Driveshafts Flange Yoke Dimension Diagram
