DANA SPICER 3-2-709 Flange Yoke 1410 Series
Part Number:
3-2-709


UPC:
023913236328
Your Cost $120.72 Sale Price $101.69
You Save $19.03
STATUS:  FACTORY DIRECT TO YOU

DANA SPICER 3-2-709

1410 Series Flange Yoke




Spicer
DANA SPICER 3-2-709 Flange Yoke 1410 Series
DANA SPICER 3-2-709 Flange Yoke 1410 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $120.72 Sale Price $101.69
You Save $19.03

DANA SPICER 3-2-709

1410 Series Flange Yoke

  • A - Flange or Swing Diameter = 6.375 inches
  • B - Bolt Circle Diameter = 5.500 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.562 inches
    • Center Pilot = FEMALE
  • Series = 1410
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.187 inches
    • D - U-Joint Bearing cap diameter = 1.187 inches
  • G - Center of u-joint bore to Face of flange = 1.844 inches
  • X - inches
  • Y - inches
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 3-2-709 Flange Yoke 1410 Series

DANA SPICER 3-2-709 Flange Yoke 1410 Series
