DANA SPICER 3-2-939 Flange Yoke 1410 Series
|
|
Your Cost
$129.96 Sale Price $109.48You Save $20.48
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 3-2-939
1410 Series Flange Yoke
UPC: 023913232924
Part Number: 3-2-939
|
DANA SPICER 3-2-939 Flange Yoke 1410 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$129.96 Sale Price $109.48You Save $20.48
|
DANA SPICER 3-2-939
1410 Series Flange Yoke
- A - Flange or Swing Diameter = 5.812 inches
- B - Bolt Circle Diameter = 4.750 inches
- Bolt Hole Diameter = 0.531 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 3.750 inches
- Series = 1410
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.187 inches
- D - U-Joint Bearing cap diameter = 1.187 inches
- G - Center of u-joint bore to Face of flange = 2 inches
- X - inches
- Y - inches
- Special Notes:
|
|
DANA SPICER 3-2-939 Flange Yoke 1410 Series
|
|
