DANA SPICER 5-2-989 Flange Yoke 1610 Series Bearing Plate Style
|
|
Your Cost
$430.95
Sorry, sold out
STATUS:
FACTORY BACK ORDER at this time
|
|
DANA SPICER 5-2-989
1610 Series Flange Yoke
UPC: 023913220143
Part Number: 5-2-989
|
GENERIC PHOTO
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY BACK ORDER at this time
YOUR COST:
$430.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 5-2-989
1610 Series Flange Yoke
- A - Flange or Swing Diameter = 6.875 inches
- B - Bolt Circle Diameter = 6.125 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 5.312 inches
- Series = 1610
- U-Joint Width = 5.312 inches
- D - U-Joint Bearing cap diameter = 1.875 inches
- G - Center of u-joint bore to Face of flange = 1.875 inches
- Special Notes: Flange has pilot for brake, Bearing Plate Style
|
|
GENERIC PHOTO
|
|
