DANA SPICER 6-2-749-1 Flange Yoke 1710 Series Half Round Bearing Strap Style
|
|
Your Cost
$265.95
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 6-2-749-1
1710 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.525 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1710
- U-Joint Width = 6.094 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3 inches
- Special Notes: Half Round BEARING STRAP Style, Part has opening cast thru web
UPC: 023913215910
Part Number: 6-2-749-1
|
DANA SPICER 6-2-749-1 Flange Yoke 1710 Series Half Round Bearing Strap Style
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$265.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 6-2-749-1
1710 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.525 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1710
- U-Joint Width = 6.094 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3 inches
- Special Notes: Half Round BEARING STRAP Style, Part has opening cast thru web
|
|
DANA SPICER 6-2-749-1 Flange Yoke 1710 Series Half Round Bearing Strap Style
|
|
