DANA SPICER 6.3-2-19-1 Flange Yoke 1760 Series
|
|
Your Cost
$254.43 Sale Price $224.34You Save $30.09
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 6.3-2-19-1
1760 Series Flange Yoke
UPC: 023913214005
Part Number: 6.3-2-19-1
|
DANA SPICER 6.3-2-19-1 Flange Yoke 1760 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$254.43 Sale Price $224.34You Save $30.09
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 6.3-2-19-1
1760 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 12
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1760
- U-Joint Width = 7 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3.375 inches
- Special Notes: Bearing strap/half round style
|
|
DANA SPICER 6.3-2-19-1 Flange Yoke 1760 Series
|
|
