DANA SPICER 6.5-2-329-1 Flange Yoke 1810 Series HALF ROUND BEARING STRAP STYLE
|
|
Your Cost
$193.95
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 6.5-2-329-1
1810 Series Flange Yoke - HALF ROUND BEARING STRAP STYLE
UPC: 023913213343
Part Number: 6.5-2-329-1
|
DANA SPICER 6.5-2-329-1 Flange Yoke 1810 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$193.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 6.5-2-329-1
1810 Series Flange Yoke - HALF ROUND BEARING STRAP STYLE
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 12
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1810
- U-Joint Width = 7.547 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3.375 inches
- Special Notes: FITS HALF ROUND U-JOINT 5-676X
|
|
DANA SPICER 6.5-2-329-1 Flange Yoke 1810 Series
|
|
