DANA SPICER 6.5-2-359 Flange Yoke 1810 Series
|
|
Your Cost
$448.22
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 6.5-2-359
1810 Series Flange Yoke
UPC: 023913212544
Part Number: 6.5-2-359
|
DANA SPICER 6.5-2-359 Flange Yoke 1810 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$448.22
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 6.5-2-359
1810 Series Flange Yoke
- A - Flange or Swing Diameter = 8.125 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 12
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1810
- U-Joint Width = 7.547 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 2.594 inches
- Special Notes:
|
|
DANA SPICER 6.5-2-359 Flange Yoke 1810 Series
|
|
