DANA SPICER 8-2-109 Flange Yoke 1880 Series
|
|
Your Cost
$468.95 Sale Price $440.89You Save $28.06
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 8-2-109
1880 Series Flange Yoke
UPC: 023913212346
Part Number: 8-2-109
|
DANA SPICER 8-2-109 Flange Yoke 1880 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$468.95 Sale Price $440.89You Save $28.06
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 8-2-109
1880 Series Flange Yoke
- A - Flange or Swing Diameter = 9.562 inches
- B - Bolt Circle Diameter = 8.250 inches
- Bolt Hole Diameter = 0.625 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7 inches
- Series = 1880
- U-Joint Width = 8.094 inches
- D - U-Joint Bearing cap diameter = 2.188 inches
- G - Center of u-joint bore to Face of flange = 3.500 inches
- Special Notes: USE WITH Dana Spicer 5-308X universal joint
|
|
