DANA SPICER 2-2-1949 Flange Yoke 1310 Series fits front diff pinion flange 2007 to 2015 Jeep JK

Part Number:
2-2-1949

UPC:

023913231682

Your Cost $31.95

STATUS: IN STOCK

DANA SPICER 2-2-1949

Flange Yoke
1310 Series
Fits front diff pinion flange Jeep JK
- 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015

Use this 1310 series flange yoke to mount a 1310 series universal joint driveshaft into OEM stock front diff pinion flange that was originally designed for the ball style high speed CV joint.

Mounts directly to stock OEM front diff companion flange

You will also need Dana Spicer 10016921 double cardan CV yoke to mount a 1310 series double cardan CV driveshaft at the transfer case end.
With part numbers 2-2-1949 and 10016921 you can install a normal 1310 series double cardan CV driveshaft into your 2007 to 2015 Jeep JK
Maximum suspension lift to use these parts is no more than 4 inches.

DANA SPICER 2-2-1949 Flange Yoke 1310 Series fits front diff pinion flange 2007 to 2015 Jeep JK

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: $31.95

DANA SPICER 2-2-1949

Flange Yoke
1310 Series
Fits front diff pinion flange Jeep JK
- 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015

Use this 1310 series flange yoke to mount a 1310 series universal joint driveshaft into OEM stock front diff pinion flange that was originally designed for the ball style high speed CV joint.

Mounts directly to stock OEM front diff companion flange

You will also need Dana Spicer 10016921 double cardan CV yoke to mount a 1310 series double cardan CV driveshaft at the transfer case end.
With part numbers 2-2-1949 and 10016921 you can install a normal 1310 series double cardan CV driveshaft into your 2007 to 2015 Jeep JK
Maximum suspension lift to use these parts is no more than 4 inches.

DIMENSIONS

A - Flange or Swing Diameter = 4.719 inches
B - Bolt Circle Diameter = 3.750 inches
- Bolt Hole Diameter = 0.481 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
C - Center Pilot Hole Diameter = 2.558 inches
- Center Pilot = MALE
Series = 1310
- Outside Snap Ring Style
- U-Joint Width between snap rings = 3.219 inches
- D - U-Joint Bearing cap diameter = 1.062 inches
G - Center of u-joint bore to Face of flange = 1.781 inches
X - 2.625 inches
Y - 2.625 inches
Special Notes: 12 MM BOLT HOLES EQUALLY SPACED

CLICK HERE : For ALL DANA SPICER Flange Yoke Part Numbers, Specifications and Dimensions

Denny's Driveshafts Flange Yoke Dimension Diagram
