Dana Spicer 10007744
CHROMOLY AXLE SHAFT
- INNER AXLE SHAFT fits JEEP Dana 30 frfont axle
- Replaces 73898-2X
RIGHT SIDE INNER AXLE SHAFT - Passenger side
- Fits Jeep Wrangler YJ, TJ, and XJ with DANA 30 front axle
- 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
DIMENSIONS
- C = 32.41 inches
- C1 = 1.16 inches
- 27 Splines
Requires 5-760X Axle U-Joint
- NOTE: Check your outer axle u-joint size to be sure it accepts 1-3/16 inch u-joint caps. See part number 5-760X.
- If you have the smaller 1-1/16 u-joint caps, see part number 5-260X, you will also need to buy a new outer axle shaft to use this inner axle shaft. 10007744 REQUIRES the outer axle to be compatible with 5-760X universal joint
|
