DOM Driveshaft Tubing 2.125 inch OD tube with .188 wall thickness 24 inch length, 2.125 x .188, 2 1/8 x 3/16

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH

Part Number:
2125-188-24

UPC:

Your Cost $66.00

STATUS: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date

DRIVESHAFT TUBING - DOM

24 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date

YOUR COST: $66.00

OVERSIZE PACKAGE: Sorry ... this item DOES NOT qualify for Free Shipping!

DRIVESHAFT TUBING - DOM

24 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

PLEASE NOTE: When purchasing more than one piece of tubing you should always CALL in your order so we can quote the shipping cost correctly. Ordering online may show a higher inaccurate cost for multiple piece orders.

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH
