Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 2-3-8001KX Slip Yoke 1310 series 16 spline 6.812 inches
Part Number:
2-3-8001KX


UPC:
023913228811
Your Cost $71.95 Sale Price $68.95
You Save $3.00
STATUS:  IN STOCK

Dana Spicer 2-3-8001KX

1310 series Slip Yoke ....Includes press on seal

Fits Front or Rear Spline and Slip Style Driveshaft

  • 16 splines and 1.375 inch Spline Diameter
  • 6.812 inches from center of u-joint bearing cap to end of yoke with seal removed.



Spicer
Dana Spicer 2-3-8001KX Slip Yoke 1310 series 16 spline 6.812 inches
Dana Spicer 2-3-8001KX Slip Yoke 1310 series 16 spline 6.812 inches
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $71.95 Sale Price $68.95
You Save $3.00

Dana Spicer 2-3-8001KX

1310 series Slip Yoke ...Includes press on seal

Designed for 1310 series u-joint.  See bottom of this page for 1310 series u-joints

  • 3 7/32 inches between snap rings
  • 1 1/16 diameter bearing caps
  • Fits 16 spline driveshaft with 1.375 spline Diameter
    • For proper fit be sure to Measure OUTSIDE DIAMETER of SPLINED SHAFT
    • Spline Drawing copyright Denny's Driveshafts
  • Includes press on seal
  • 6.812 inches from center of u-joint bearing cap to end of yoke with seal removed.
    • Measure from CENTER of Bearing Cap Hole to END of Yoke with seal removed
    • Slip Yoke Drawing copyright Denny's Driveshafts
Dana Spicer 2-3-8001KX Slip Yoke 1310 series 16 spline 6.812 inches

Dana Spicer 2-3-8001KX Slip Yoke 1310 series 16 spline 6.812 inches
