DANA SPICER 2-2-03489 Flange Yoke 1330 Series with 2.953 female pilot
Part Number:
2-2-03489


UPC:
023913236823
Your Cost $63.95
STATUS:  IN STOCK

DANA SPICER 2-2-03489

1330 Series Flange Yoke




Spicer
DANA SPICER 2-2-03489 Flange Yoke 1330 Series with 2.953 female pilot
DANA SPICER 2-2-03489 Flange Yoke 1330 Series with 2.953 female pilot
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $63.95

DANA SPICER 2-2-03489

1330 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.875 inches
  • B - Bolt Circle Diameter = 4.750 inches
    • Bolt Hole Diameter = 0.500 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.953 inches
    • Center Pilot = FEMALE
  • Series = 1330
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.062 inches
  • G - Center of u-joint bore to Face of flange = 1.730 inches
  • X - inches
  • Y - inches
  • Special Notes: 12 mm bolt holes equally spaced. Part has hole thru center





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 2-2-03489 Flange Yoke 1330 Series with 2.953 female pilot

DANA SPICER 2-2-03489 Flange Yoke 1330 Series with 2.953 female pilot
