Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end

Part Number:
3-4-8681-1

UPC:

023913231408

Your Cost $175.95

STATUS: FACTORY DIRECT - SPECIAL ORDER

Dana Spicer 3-4-8681-1

Strap and bolt style

PINION YOKE

1350 series
Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
- 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
DOES NOT FIT 14 bolt Full Floater with bolt in axles
DOES NOT have a dust shield
- See 3-4-8691-1X at bottom of page for same yoke with dust shield
Use with seal part number 3896 ... see bottom of this page
Use with strap and bolt set 3-70-28X ... see bottom of page

DIMENSIONS

1350 series
30 SPLINE
SPLINE OD = 1.312
D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: FACTORY DIRECT - SPECIAL ORDER

YOUR COST: $175.95

>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<

Dana Spicer 3-4-8681-1

Strap and bolt style

PINION YOKE

1350 series
Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
- 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
DOES NOT FIT 14 bolt Full Floater with bolt in axles
DOES NOT have a dust shield
- See 3-4-8691-1X at bottom of page for same yoke with dust shield
Use with seal part number 3896 ... see bottom of this page
Use with strap and bolt set 3-70-28X ... see bottom of page

DIMENSIONS

1350 series
30 SPLINE
SPLINE OD = 1.312
D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

Dana Spicer 3-4-8681-1 Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end

You May Also Need These Parts to Complete the Job

8510 PINION NUT and WASHER Set fits GM 9.5 inch 14 BOLT REAR Part#: 8510 $4.95	Timken 3896 Pinion seal for 1981 to 1997 GM 9.5 Inch 14 Bolt Rear End Part#: 3896 $16.10
Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end Strap and Bolt style Part#: 3-4-8691-1X $88.95	DANA SPICER 3-70-28X Strap and Bolt set fits 1350/1410 series Dana 60, 61, 70, 80 rear end yokes designed for 1.187 diameter u-joint bearing caps Part#: 3-70-28X $7.95
