Dana Spicer 211631XKT 1330 Double Cardan CV Head Assembly KIT fits Ford Bronco, F150, F250, F350 with 4.25 inch bolt circle and 2 inch pilot on transfer case flange

Part Number:
211631XKT

UPC:

Your Cost $220.95

STATUS: IN STOCK - FREE SHIPPING

Dana Spicer 211631XKT

Double Cardan CV KIT

Fits Ford Bronco, F150, F250, F350 OEM and aftermarket 1330 series FRONT driveshafts that are built with a NON greaseable stud yoke.
- DOES NOT FIT any greaseable style 1330 series stud yokes
Fits transfer case output flange with 4.25 inch bolt circle and 2 inch pilot diameter
1330 Series NON Greaseable Center yoke
- Needle Bearing Ball Socket fits 1/2 inch stud yoke

Dana Spicer 211631XKT 1330 Double Cardan CV Head Assembly KIT fits Ford Bronco, F150, F250, F350 with 4.25 inch bolt circle and 2 inch pilot on transfer case flange

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: $220.95

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

Dana Spicer 211631XKT

Double Cardan CV KIT

Fits Ford Bronco, F150, F250, F350 OEM and aftermarket 1330 series FRONT driveshafts that are built with a NON greaseable stud yoke.
- DOES NOT FIT any greaseable style 1330 series stud yokes
Fits transfer case output flange with 4.25 inch bolt circle and 2 inch pilot diameter
1330 Series NON Greaseable Center yoke
- Needle Bearing Ball Socket fits 1/2 inch stud yoke

INCLUDES

(1) 1330 Dana Spicer NON Greaseable CV centering yoke
(1) 1330 Dana Spicer H-Yoke
(2) 1330 Dana Spicer NON Greaseable universal Joints
(1) 2-86-418 Dana Spicer Rubber Boot

DIMENSIONS

Bolt Circle.... 4.25 inches measured diagonally
Pilot Diameter... 2.0 inches
Fits universal joint 3.625 inches cap to cap (3 5/8 inches)
Fits u-joint bearing cap diameter 1.062 inches (1 1/16 inches)

Dana Spicer 211631XKT 1330 Double Cardan CV Head Assembly KIT fits Ford Bronco, F150, F250, F350 with 4.25 inch bolt circle and 2 inch pilot on transfer case flange

You May Also Need These Parts to Complete the Job

42-1855 BOLT Set M12-1.75 for Ford Transmission/Transfer Case Flange - 12mm 12 point bolt set
Part#: 42-1855

$11.95

DE-15688 Installation Tool for use with Rubber Boot Part Number 2-86-418
Part#: DE-15688

$32.95
