Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end Strap and Bolt style

Part Number:
3-4-8691-1X

UPC:

023913231095

Your Cost $88.95

STATUS: IN STOCK

Dana Spicer 3-4-8691-1X

PINION YOKE

1350 series
Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
- 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
DOES NOT FIT 14 bolt Full Floater with bolt in axles
DOES NOT have a dust shield
Use with seal part number 3896 ... see bottom of this page

DIMENSIONS

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end Strap and Bolt style

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: $88.95

Dana Spicer 3-4-8691-1X

PINION YOKE

1350 series
Fits Chevy and GMC 9.5 inch 14 bolt rear end.... with "C" clip axles
- 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
DOES NOT FIT 14 bolt Full Floater with bolt in axles.
DOES NOT have a dust shield
Use with seal part number 3896 ... see bottom of this page

DIMENSIONS

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series 30 spline fits 1981 to 1997 Chevy and GMC 9.5 inch 14 Bolt rear end Strap and Bolt style
