8.5 inch 10 Bolt REAR End Parts > YOKES

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series Chevy and GM fits 8.5 inch 10 Bolt 30 spline Strap and Bolt style

Part Number:
3-4-8691-1X

UPC:

023913231095

Your Cost $88.95

STATUS: IN STOCK

Dana Spicer 3-4-8691-1X

1350 series cast pinion yoke

Strap and Bolt style

Fits Chevy and GM Corporate 8.5 inch 10 bolt REAR
30 splines
SPLINE OD = 1.312

D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

Spicer

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series Chevy and GM fits 8.5 inch 10 Bolt 30 spline Strap and Bolt style

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series Chevy and GM fits 8.5 inch 10 Bolt 30 spline Strap and Bolt style

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: $88.95

Dana Spicer 3-4-8691-1X

1350 series cast pinion yoke

Strap and Bolt style

Fits Chevy and GM Corporate 8.5 inch 10 bolt REAR
30 splines
SPLINE OD = 1.312

D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

image/jpeg

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series Chevy and GM fits 8.5 inch 10 Bolt 30 spline Strap and Bolt style

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series Chevy and GM fits 8.5 inch 10 Bolt 30 spline Strap and Bolt style

You May Also Need These Parts to Complete the Job

8510 PINION NUT and WASHER Set fits GM 8.5 inch and 8.6 inch 10 BOLT Part#: 8510 $4.95	Timken 2043 Pinion seal for GM 8.5 Inch 10 Bolt Rear End Part#: 2043 $10.95
Neapco 2-0053G universal joint 1350 Series non greaseable 3.622 x 1.188 Part#: 2-0053G ~~$24.10~~ $22.95	Dana Spicer 5-178X Greaseable u-joint 1350 Series Part#: 5-178X $20.95
Dana Spicer 5-1350-1X GREASEABLE Universal Joint 1350 Series fitting in end of bearing cap Part#: 5-1350-1X $32.60	Dana Spicer 5-1350X Universal Joint NON Greaseable 1350 series cold forged solid body heat treated precision ground and case hardened with multi lip seals Part#: 5-1350X $23.54
