DANA SPICER 1-2-39 Fits 1100/1110 Series flange yoke with 2.250 pilot
|
|
Your Cost
$43.95
Sorry, sold out
STATUS:
OBSOLETE - NO LONGER AVAILABLE
|
|
DANA SPICER PTO FLANGE YOKE for power take off applications
PART NUMBER: 1-2-39
UPC: 023913232696
Part Number: 1-2-39
|
DANA SPICER 1-2-39 Fits 1100/1110 Series flange yoke with 2.250 pilot
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: OBSOLETE - NO LONGER AVAILABLE
YOUR COST:
$43.95
|
DANA SPICER FLANGE YOKE for power take off applications
PART NUMBER: 1-2-39
- SERIES 1100/1110
- C - MALE PILOT DIAMETER - 2.250 INCHES
- D - U-JOINT BEARING CAP DIAMETER - .938 INCHES
- E - WIDTH OF YOKE - 2.656 INCHES
- G - FLANGE FACE TO CENTERLINE - 1.188 INCHES
- A - FLANGE SWING DIAMETER - 3.5 INCHES
- B - BOLT CIRCLE DIAMETER - 2.75 INCHES
- 4 BOLT HOLES .312 DIAMETER
- JOINT ANGLE - 18 DEGREES
- OUTSIDE SNAP RING
|
|
DANA SPICER 1-2-39 Fits 1100/1110 Series flange yoke with 2.250 pilot
|
|
