Neapco N3-4-JL05-1X Pinion Yoke 24 splines 1350 series to replace OEM companion flange Jeep JL M186 Dana 30 AdvanTEK FRONT END
Part Number:
N3-4-JL05-1X


UPC:
083869025223
Your Cost $61.92
STATUS:  IN STOCK

Neapco N3-4-JL05-1X

Pinion Yoke

  • 1350 series pinion yoke to replace OEM flat companion flange
    • Fits Jeep JL M186 Dana 30 AdvanTEK FRONT END
    • This pinion yoke bolts onto Jeep JL FRONT DIFF to replace OEM companion flange
  • U-Bolt style
  • Length Thru Hole(In): 1.430
  • Spline OD(In): 1.250
  • Splines: 24
  • Center Line UJ To End Of Hub (In): 3.000
  • Seal Surface Diameter (In): 1.875
  • U-Joint saddle: 1.188
  • Width between tabs: 3.625
  • Counterbore depth: 0.375
  • Counterbore diameter: 1.280

INCLUDES

  • 1350 U-Bolt Set
Neapco
Neapco N3-4-JL05-1X Pinion Yoke 24 splines 1350 series to replace OEM companion flange Jeep JL M186 Dana 30 AdvanTEK FRONT END
Neapco N3-4-JL05-1X Pinion Yoke 24 splines 1350 series to replace OEM companion flange Jeep JL M186 Dana 30 AdvanTEK FRONT END
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $61.92

Neapco N3-4-JL05-1X

Pinion Yoke

  • 1350 series pinion yoke to replace OEM flat companion flange
    • Fits Jeep JL M186 Dana 30 AdvanTEK FRONT END
    • This pinion yoke bolts onto Jeep JL FRONT DIFF to replace OEM companion flange
  • U-Bolt style
  • Length Thru Hole(In): 1.430
  • Spline OD(In): 1.250
  • Splines: 24
  • Center Line UJ To End Of Hub (In): 3.000
  • Seal Surface Diameter (In): 1.875
  • U-Joint saddle: 1.188
  • Width between tabs: 3.625
  • Counterbore depth: 0.375
  • Counterbore diameter: 1.280

INCLUDES

  • 1350 U-Bolt Set
Neapco N3-4-JL05-1X Pinion Yoke 24 splines 1350 series to replace OEM companion flange Jeep JL M186 Dana 30 AdvanTEK FRONT END

Neapco N3-4-JL05-1X Pinion Yoke 24 splines 1350 series to replace OEM companion flange Jeep JL M186 Dana 30 AdvanTEK FRONT END
