DT Components DRK-325BMK Master Bearing Kit fits GM 10.5 inch 14 bolt rear end Chevy and GMC 1998 to 2018

Part Number:
DRK-325BMK

UPC:

Your Cost ~~$230.95~~ Sale Price $220.95

You Save $10.00

Sorry, sold out

CLICK HERE to be NOTIFIED when this item is available

STATUS: SOLD OUT...More Coming Soon

Part Number: DRK325BMK

DRK-325BMK Master Differential Bearing and Seal Kit - DT Components

Fits GM 10.5 inch 14 bolt rear end

Fits Chevy/GMC 3/4 ton TRUCK - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
Fits Chevy/GMC 1 ton TRUCK - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015
Fits Chevy/GMC 3/4 ton and 1 ton VAN - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
Fits Chevy/GMC SUV- with 10.5 inch 14 bolt full floater rear end
- Avalanche 2500 - 2002, 2003, 2004, 2005, 2006
- Yukon XL 2500 - 2008, 2009, 2010, 2011, 2012, 2013
- Suburban 2500 - 2008, 2009, 2010, 2011, 2012, 2013
- Suburban 3500 HD - 2016, 2017, 2018, 2019

DT Components DRK-325BMK Master Bearing Kit fits GM 10.5 inch 14 bolt rear end Chevy and GMC 1998 to 2018

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: SOLD OUT...More Coming Soon

YOUR COST: ~~$230.95~~ Sale Price $220.95

You Save $10.00

Part Number: DRK325BMK

DRK-325BMK Master Differential Bearing and Seal Kit - DT Components

Fits GM 10.5 inch 14 bolt rear end

Fits Chevy/GMC 3/4 ton TRUCK - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
Fits Chevy/GMC 1 ton TRUCK - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015
Fits Chevy/GMC 3/4 ton and 1 ton VAN - with 10.5 inch 14 bolt full floater rear end
- 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
Fits Chevy/GMC SUV- with 10.5 inch 14 bolt full floater rear end
- Avalanche 2500 - 2002, 2003, 2004, 2005, 2006
- Yukon XL 2500 - 2008, 2009, 2010, 2011, 2012, 2013
- Suburban 2500 - 2008, 2009, 2010, 2011, 2012, 2013
- Suburban 3500 HD - 2016, 2017, 2018, 2019

Parts included in DRK-325BMK

(2) Differential Bearing: 387AS - 382A
(1) Pinion Head Bearing: HM903249 - HM903210
(1) Pinion Tail Bearing: M802048 - M802011

(1) Pinion Nose Bearing: R1581TV

(1) Pinion Seal: 710508 (2.324 x 3.541)
(1) Crush Sleeve: CS325A
(1) Pinion Nut: PN7
(1) Gear Marking & Brush: GMC1-BR1
(1) Threadlocker: TL1
(1) Sealer RTV Silicone
(1) Pinion Depth Shims: SK14
(12) Ring Gear Bolts: RGB9

DT Components DRK-325BMK Master Bearing Kit fits GM 10.5 inch 14 bolt rear end Chevy and GMC 1998 to 2018
