Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tube

Part Number:
3-53-1791

UPC:

023913231927

Your Cost ~~$117.82~~ Sale Price $109.68

You Save $8.14

STATUS: IN STOCK - FREE SHIPPING

DANA SPICER 3-53-1781

MIDSHIP STUB SPLINE

Use with 1.574 ID Center Support Bearing

1.500 inch diameter spline
10 SPLINES
- Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
  - Butt diameter = 2.845
- Major SPLINE Diameter = 1.500
- SPLINES = 10
- STYLE = 2
- B = 1.810
- C = 1.574
- G = .875
- K = 3.875
- L = 1.940
- Y = 2.750
- Thread size = 1.0 - 20
SPECIAL NOTES:
- Requires nut 16-74-101 ...see bottom of this page
- Use with center bearing 210873-1X ...see bottom of this page
- Use with end yoke 3-4-6561-1 for 1410 series ...see bottom of this page
- Use with end yoke 3-4-6901-1 for 1480 series ...see bottom of this page

Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tubing

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: ~~$117.82~~ Sale Price $109.68

You Save $8.14

DANA SPICER 3-53-1791

MIDSHIP STUB SPLINE

Use with 1.574 ID Center Support Bearing

1.500 inch diameter spline
10 SPLINES
- Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
  - Butt diameter = 3.345
- Major SPLINE Diameter = 1.500
- SPLINES = 10
- STYLE = 2
- B = 1.810
- C = 1.574
- G = .890
- K = 3.880
- L = 1.940
- Y = 2.750
- Thread size = 1.0 - 20
SPECIAL NOTES:
- Requires nut 16-74-101 ...see bottom of this page
- Use with center bearing 210873-1X ...see bottom of this page
- Use with end yoke 3-4-6561-1 for 1410 series ...see bottom of this page
- Use with end yoke 3-4-6901-1 for 1480 series ...see bottom of this page

Two piece driveshaft parts at Denny's Driveshafts

Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tubing

You May Also Need These Parts to Complete the Job

Dana Spicer 16-74-101 Nut for Midship Stub Spline 1.00-20 thread Part#: 16-74-101 $7.95	DANA SPICER 210873-1X Center Support Bearing 1.574 ID Part#: 210873-1X $34.95
Dana Spicer 3-4-6561-1 End Yoke 1.500-10 spline 1410 series strap and bolt style fits Midship Stub Spline for use in 2 piece driveshafts with center support bearing Part#: 3-4-6561-1 $49.95	Dana Spicer 3-4-6901-1 End Yoke 1.500-10 spline 1480 series strap and bolt style fits Midship Stub Spline for use in 2 piece driveshafts with center support bearing Part#: 3-4-6901-1 $65.08
