DANA SPICER 2-4-2801-1X Pinion Yoke 1310 series fits 1941 to 1968 Jeep CJ2A, CJ3A, CJ3B, CJ5, CJ6 with Dana 25, 27, 41, 44 with 10 Spline pinion front or rear

Part Number:
2-4-2801-1X

UPC:

023913234393

Your Cost ~~$88.06~~ Sale Price $73.75

You Save $14.31

Sorry, sold out

CLICK HERE to be NOTIFIED when this item is available

STATUS: SOLD OUT...More Coming Soon

DANA SPICER 2-4-2801-1X

10 spline pinion yoke

Strap and Bolt Style
Fits 1310 Series universal joint 3 7/32 inches wide with 1 1/16 inch bearing caps.
10 splines
SPLINE DIAMETER = 1.125

DANA SPICER 2-4-2801-1X Pinion Yoke 1310 series fits 1941 to 1968 Jeep CJ2A, CJ3A, CJ3B, CJ5, CJ6 with Dana 25, 27, 41, 44 with 10 Spline pinion front or rear

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: SOLD OUT...More Coming Soon

YOUR COST: ~~$88.06~~ Sale Price $73.75

You Save $14.31

Dana Spicer 2-4-2801-1X

1310 Series Pinion Yoke
- Strap and Bolt Style
- 1.125 x 10 Spline
- Replaces obsolete Dana Spicer 2-4-2821X

Fits Jeep CJ2A, CJ3A, CJ3B, CJ5, CJ6 with Dana 25, 27, 41, 44 with 10 Spline pinion front or rear

Fits Kaiser Willys MB, Ford GPW and early CJ2A with full floating type Dana 27 REAR axle
- 1941, 1942, 1943, 1944, 1945
Fits Jeep CJ with Dana 25 FRONT axle
- 1945, 1946, 1947, 1948, 1949, 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965
Fits Jeep CJ, Willys Wagon, Willys Pickup, Jeepster VJ with Dana 41 REAR axle
- 1946, 1947, 1948, 1949, 1950
Fits Jeep CJ with Dana 44 REAR axle....with tapered axle shafts
- 1948, 1949, 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968
Fits International Scout 80 with Dana 27 Front or Rear axle
- 1961, 1962, 1963, 1964, 1965

DIMENSIONS

SPLINE OD = 1.125
SPLINES = 10

D = 1.062

E = 3.219

Q = 1.500

R = 1.552

S = 3.000

DANA SPICER 2-4-2801-1X Pinion Yoke 1310 series fits 1941 to 1968 Jeep CJ2A, CJ3A, CJ3B, CJ5, CJ6 with Dana 25, 27, 41, 44 with 10 Spline pinion front or rear

You May Also Need These Parts to Complete the Job

Dana Spicer 5-153X Universal Joint Greaseable 1310 series 3.219 x 1.062 outside snap rings Part#: 5-153X $13.10	Dana Spicer 5-1310X Universal Joint 1310 Series NON Greaseable 3.219 x 1.062 outside snap rings Part#: 5-1310X $19.66
Neapco 1-0153 Greaseable universal joint 1310 series 3.219 x 1.062 outside snap rings Part#: 1-0153 ~~$15.76~~ $14.95	Dana Spicer 2-70-18X Strap and Bolt set fits 1.062 bearing cap diameter 1.587 CL on 1310 and 1330 Dana Spicer pinion yokes and transfer case yokes Part#: 2-70-18X $7.55
