DANA SPICER 5-260X - 4x4 Front Axle Universal Joint fits CHEVY and GMC 1969 to 1972 ALL with 1.062 u-joint bearing cap diameter
|
|
Your Cost
$29.95
STATUS:
IN STOCK
|
|
DANA SPICER 5-260X - 4x4 Front Axle U-joint.
UPC: 023913121112
Part Number: 5-260X
|
Dana Spicer 5-260X - 4x4 Front Axle Universal Joint
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: IN STOCK
YOUR COST:
$29.95
|
DANA SPICER 5-260X
Commonly known as the "Small" axle u-joint.
This u-joint was found on early Jeep, Bronco, Chevy, Dodge, International and Ford 4X4 trucks before they realized that it was too small and started to use the larger and stronger 5-760X.
Easy to spot on open knuckle front ends by measuring the bearing cap diameter.
Utilizes inside "C" Clips to lock u-joint in place.
- Dimension A = 2.188 inches ( 2 3/16 inches )
- Dimension B = 2.188 inches ( 2 3/16 inches )
- Dimension C = 1.062 inches ( 1 1/16 inches )
- Dimension D = 1.062 inches ( 1 1/16 inches )
- Non Greaseable
Application Chart
-
1969 - 1972 Chevy K-5 Blazer & GMC Jimmy... all 1 1/16 inch diameter bearing cap
-
1970 - 1972 Chevy K-10 & K-20, GMC K-15, K-25 Pick-Up... all 1 1/16 inch diameter bearing cap
|
|
Dana Spicer 5-260X - 4x4 Front Axle Universal Joint
|
|
