Dana Spicer 2-1-1313-3 PTO Companion Flange 1.250 inch Round Bore with 0.250 Keyway, 3.125 Bolt Circle, 2.375 female pilot

Part Number:
2-1-1313-3

UPC:

023913234386

Your Cost $169.95

STATUS: FACTORY DIRECT - SPECIAL ORDER

Dana Spicer 2-1-1313-3

PTO Companion Flange

1.250 inch Round Bore
0.250 Keyway
3.125 Bolt Circle
2.375 female pilot
1280/1310 series

Dana Spicer 2-1-1313-3 PTO Companion Flange 1.250 inch Round Bore with 0.250 Keyway, 3.125 Bolt Circle, 2.375 female pilot

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: FACTORY DIRECT - SPECIAL ORDER

YOUR COST: $169.95

>>>>> SPECIAL ORDER PART: This part number is a special order. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<

Dana Spicer 2-1-1313-3

COMPANION FLANGE for power take off applications

Series 1280, 1310

P - 1.250 Inch Diameter Bore
- X - 0.250 in. Keyway
C - 2.375 in Female Pilot
B - Bolt Circle Diameter - 3.125 in
- 4 Bolt Holes 0.375 in. Diameter Drilled
- Bolt Pattern - Rectangular
  - 2.0 inches
  - 2.375 inches

W - Set Screw THREAD Diameter - 0.375 in.
- W - Set Screw Location - 12
- Set Screw Included

R - Hub Diameter - 2.438 in.
F - Length Through Hole - 1.900 in.
G - Flange Face to End of Hub - 2.000 in.
A - Total Swing Diameter - 3.875 in.

Dana Spicer 2-1-1313-3 PTO Companion Flange 1.250 inch Round Bore with 0.250 Keyway, 3.125 Bolt Circle, 2.375 female pilot
