DANA SPICER 3-2-119 Flange Yoke 1350 Series
Part Number:
3-2-119


UPC:
023913229009
Your Cost $32.95
STATUS:  IN STOCK

DANA SPICER 3-2-119

1350 Series Flange Yoke




Spicer
DANA SPICER 3-2-119 Flange Yoke 1350 Series
DANA SPICER 3-2-119 Flange Yoke 1350 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $32.95

DANA SPICER 3-2-119

1350 Series Flange Yoke

  • A - Flange or Swing Diameter = 4.625 inches
  • B - Bolt Circle Diameter = 3.750 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 2.750 inches
    • Center Pilot = MALE
  • Series = 1350
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 3.625 inches
    • D - U-Joint Bearing cap diameter = 1.187 inches
  • G - Center of u-joint bore to Face of flange = 1.562 inches
  • X - inches = 2.875
  • Y - inches = 2.410
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram
