DANA SPICER 4-2-669 Flange Yoke 1550 Series
Part Number:
4-2-669


UPC:
023913212513
Your Cost $120.95
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 4-2-669

1550 Series Flange Yoke




Spicer
DANA SPICER 4-2-669 Flange Yoke 1550 Series
DANA SPICER 4-2-669 Flange Yoke 1550 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $120.95

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 4-2-669

1550 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.774 inches
  • B - Bolt Circle Diameter = 4.750 inches
    • Bolt Hole Diameter = 0.512 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.750 inches
    • Center Pilot = MALE
  • Series = 1550
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.964 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 2 inches
  • Special Notes: Use with Dana Spicer 5-155X, 5-808X or 5-809X universal joint





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 4-2-669 Flange Yoke 1550 Series

DANA SPICER 4-2-669 Flange Yoke 1550 Series
