Dana Spicer 3-40-2171 Spline 23 based on 24 with 1.563 spline diameter fits 3.5 x 0.083 wall tube
|
|
Your Cost
$76.95
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 3-40-2171
23/24 SPLINES Fits 3.5 inch 0.083 wall tubing
UPC: 023913230999
Part Number: 3-40-2171
|
Dana Spicer 3-40-2171 Spline 23 based on 24 with 1.563 spline diameter fits 3.5 x 0.083 wall tube
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$76.95
|
DANA SPICER 3-40-2171
23/24 SPLINES Fits 3.5 inch 0.083 wall tubing
- Fits SLIP YOKE designed for 23/24 splines with a 1.563 inch diameter spline
- Fits TUBE DIAMETER = 3.500 OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = 0.083 inch Tube wall thickness
- Butt Diameter = 3.345
- Major SPLINE Diameter = 1.563
- SPLINES = 23 based on 24
- K = 8.000
- L = 3.000
- R = 7.060
- Glidecoated spline for wear resistance
|
|
Dana Spicer 3-40-2171 Spline 23 based on 24 with 1.563 spline diameter fits 3.5 x 0.083 wall tube
|
|
