Dana Spicer 10016266 Transfer Case Yoke 32 spline 1310 series Double Cardan CV style fits 2007 to 2018 JEEP Wrangler JK, 2018 and newer JL fits FRONT output

Part Number:
10016266

UPC:

023913463564

Your Cost ~~$93.84~~ Sale Price $78.59

You Save $15.25

Sorry, sold out

STATUS: Not available at this time

DANA SPICER 10016266

CV End Yoke
1310 Series
32 splines
1.875 inch Seal Surface Diameter
4.00 inches CL to END
Fits front output on transfer case Jeep JK
- 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
Fits front output on transfer case Jeep JL
- 2018 and newer

Use this 1310 series CV end yoke to mount a 1310 series double cardan CV driveshaft onto transfer case front output.

Replaces stock OEM transfer case front companion flange designed for ball style high speed CV joint

You will also need Dana Spicer 2-2-1949 flange yoke to mount a 1310 series driveshaft at the front diff end.
With part numbers 2-2-1949 and 10016266 you can install a normal 1310 series double cardan CV driveshaft into your 2007 to 2015 Jeep JK
Maximum suspension lift to use these parts is no more than 4 inches.

Dana Spicer 10016266 replaces old number 10016921

Dana Spicer 10016266 Transfer Case Yoke 32 spline 1310 series Double Cardan CV style fits 2007 to 2018 JEEP Wrangler JK, 2018 and newer JL fits FRONT output

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: Not available at this time

YOUR COST: ~~$93.84~~ Sale Price $78.59

You Save $15.25

DANA SPICER 10016266

CV End Yoke
1310 Series
32 splines
1.875 inch Seal Surface Diameter
4.00 inches CL to END
Fits front output on transfer case Jeep JK
- 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
Fits front output on transfer case Jeep JL
- 2018 and newer

Use this 1310 series CV end yoke to mount a 1310 series double cardan CV driveshaft onto transfer case front output.

Replaces stock OEM transfer case front companion flange designed for ball style high speed CV joint

You will also need Dana Spicer 2-2-1949 flange yoke to mount a 1310 series driveshaft at the front diff end.
With part numbers 2-2-1949 and 10016266 you can install a normal 1310 series double cardan CV driveshaft into your 2007 to 2015 Jeep JK
Maximum suspension lift to use these parts is no more than 4 inches.

Dana Spicer 10016266 replaces old number 10016921

Dana Spicer 10016266 Transfer Case Yoke 32 spline 1310 series Double Cardan CV style fits 2007 to 2018 JEEP Wrangler JK, 2018 and newer JL fits FRONT output
