Driveshaft and Driveline Parts > SPINDLES > JEEP > DANA 44 Front Axle with DISC BRAKES

Dana Spicer 10086725 SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

Part Number:
10086725

UPC:

Your Cost $74.95

Sorry, sold out

CLICK HERE to be NOTIFIED when this item is available

STATUS: SOLD OUT...More Coming Soon

DANA SPICER 10086725

Replaces obsolete Dana Spicer 706528X
SPINDLE with internal bearing, spindle seals and thrust washer
- 6 Bolt Holes
Fits Jeep Wagoneer with Disc Brakes DANA 44 front axle
- 1974, 1975, 1976
Fits Jeep Cherokee with Disc Brakes DANA 44 front axle
- 1974, 1975, 1976

Spicer

Dana Spicer 10086725 SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

Dana Spicer 10086725 SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: SOLD OUT...More Coming Soon

YOUR COST: $74.95

DANA SPICER 10086725

Replaces obsolete Dana Spicer 706528X
SPINDLE with internal bearing, spindle seals and thrust washer
- 6 Bolt Holes
Fits Jeep Wagoneer with Disc Brakes DANA 44 front axle
- 1974, 1975, 1976
Fits Jeep Cherokee with Disc Brakes DANA 44 front axle
- 1974, 1975, 1976

DIMENSIONS:

KEYWAY SLOT = .250 in. wide (1/4 inch)
BORE ID = 1.300 inches
A = 1.622 in. OD for Outer Wheel Bearing
B = 1.778 in. OD for Inner Wheel Bearing
C = 2-1/2 in. OD for Seal
D = 3-3/8 in.
E = 7/16 in.
F = 3/8 in.
G = 5-5/8 in.
H = 6-1/2 in.
K = 4-3/4 in.
Bolt Holes = 6
Bolt Hole Diameter = .400 in.

INCLUDES

(1) Internal bearing factory installed
(2) Rubber seals
(1) Thrustwasher

How to Measure a 4X4 Front Axle Spindle at Denny's Driveshafts

Dana Spicer 10086725 SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

Dana Spicer 10086725 SPINDLE fits 1974, 1975, 1976 Jeep Wagoneer and Cherokee with Disc Brakes Dana 44 front axle

You May Also Need These Parts to Complete the Job

DANA SPICER 31139 Outer Spindle Nut for DANA 44 and DANA 44IFS FRONT Part#: 31139 $6.34	DANA SPICER 21588X Inner Spindle Nut WITH PIN for DANA 44 and DANA 44IFS FRONT Part#: 21588X $12.95
DANA SPICER 28068X Spindle Nut Set for DANA 30, 44 and GM 8.5 inch FRONT 1.625-16 thread size Part#: 28068X $16.95	DANA SPICER 36569 - Spindle Washer Locking Ring with holes for Manual Locking Hubs Part#: 36569 $2.54
