Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 5-648X Combination U-joint greaseable 1330 Series 3.625 x 1.062 to 1350 Series 3.625 x 1.188 outside snap ring style
Part Number:
5-648X


UPC:
Your Cost $38.95
STATUS:  IN STOCK

Dana Spicer 5-648X

1330 to 1350 Series Spicer Combination Universal Joint.  This is a very popular and handy u-joint when connecting mismatched driveline components.

Use this to connect 1330 series components to 1350 series components.

GREASEABLE U-Joint
  • Grease Fitting in body of u-joint
DIMENSIONS
  • 1330 series dimensions
    • Dimension A = 3.625 inches wide
    • Dimension C = 2 bearing caps are 1.0625 inch diameter
    • Outside snap rings
  • 1350 series dimensions
    • Dimension B = 3.625 inches wide
    • Dimension D = 2 bearing caps are 1.188 inch diameter
    • Outside snap rings
Spicer
Dana Spicer 5-648X Combination U-joint greaseable 1330 Series 3.625 x 1.062 to 1350 Series 3.625 x 1.188 outside snap ring style
Dana Spicer 5-648X Combination U-joint greaseable 1330 Series 3.625 x 1.062 to 1350 Series 3.625 x 1.188 outside snap ring style
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $38.95

Dana Spicer 5-648X

1330 to 1350 Series Spicer Combination Universal Joint.  This is a very popular and handy u-joint when connecting mismatched driveline components.

Use this to connect 1330 series components to 1350 series components.

GREASEABLE U-Joint
  • Grease Fitting in body of u-joint
DIMENSIONS
  • 1330 series dimensions
    • Dimension A = 3.625 inches wide
    • Dimension C = 2 bearing caps are 1.0625 inch diameter
    • Outside snap rings
  • 1350 series dimensions
    • Dimension B = 3.625 inches wide
    • Dimension D = 2 bearing caps are 1.188 inch diameter
    • Outside snap rings




image/jpeg
Dana Spicer 5-648X Combination U-joint greaseable 1330 Series 3.625 x 1.062 to 1350 Series 3.625 x 1.188 outside snap ring style

Dana Spicer 5-648X Combination U-joint greaseable 1330 Series 3.625 x 1.062 to 1350 Series 3.625 x 1.188 outside snap ring style
