400083-411 Spline and Slip yoke set 1410 series fits 4.0 inch 0.083 wall steel tube allows maximum 3.000 inches of slip travel

Part Number:
400083-411

UPC:

Your Cost $165.95

STATUS: IN STOCK - FREE SHIPPING

400083-411

Spicer Spline and Slip yoke set

Fits 4.0 inch steel tube OD with 0.083 wall thickness
Fits 1410 series universal joint (see choices at bottom of page)
- 4.188 wide cap to cap
- 1.188 cap diameter
- outside snap rings
Maximum of 3.000 inches slip travel
Spicer Slip yoke 1.500 x 16 splines, grease fitting in slip yoke barrel, has screw on seal
Spicer Spline is glidecoated (blue coating) 3.00 inches for wear resistance if properly lubricated
- Spline butt diameter to press fit into tube - 3.845 inches

400083-411 Spline and Slip yoke set 1410 series fits 4.0 inch 0.083 wall steel tube allows maximum 3.000 inches of slip travel

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: $165.95

400083-411

Spicer Spline and Slip yoke set

Fits 4.0 inch steel tube OD with 0.083 wall thickness
Fits 1410 series universal joint (see choices at bottom of page)
- 4.188 wide cap to cap
- 1.188 cap diameter
- outside snap rings
Maximum of 3.000 inches slip travel
Spicer Slip yoke 1.500 x 16 splines, grease fitting in slip yoke barrel, has screw on seal
Spicer Spline is glidecoated (blue coating) 3.00 inches for wear resistance if properly lubricated
- Spline butt diameter to press fit into tube - 3.845 inches

The following dimensions are taken with the supplied seal installed.

**CL to weld Collapsed Dimension - xxx inches
**CL to weld Dimension at MID travel - xxx inches
CL to weld Fully Extended Dimension - xxx inches

**Caution --- Using a rubber boot in place of the seal will lengthen the collapsed and mid point dimensions. You must factor this into your build dimensions before cutting, welding and building the driveshaft

Copywrite Denny's Driveshafts

400083-411 Spline and Slip yoke set 1410 series fits 4.0 inch 0.083 wall steel tube allows maximum 3.000 inches of slip travel
