DANA SPICER 90-2-19 Flange Yoke SPL90 Series
|
|
Your Cost
$142.46
STATUS:
FACTORY DIRECT - SPECIAL ORDER
|
|
DANA SPICER 90-2-19
SPL90 Series Flange Yoke
UPC: 023913261894
Part Number: 90-2-19
|
DANA SPICER 90-2-19 Flange Yoke SPL90 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT - SPECIAL ORDER
YOUR COST:
$142.46
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 90-2-19
SPL90 Series Flange Yoke
- A - Flange or Swing Diameter = 6.688 inches
- B - Bolt Circle Diameter = 6.124 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 6.624 inches
- Series = SPL90
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.957 inches
- D - U-Joint Bearing cap diameter = 1.625 inches
- G - Center of u-joint bore to Face of flange = 3.280 inches
- Special Notes:
|
|
