DANA SPICER 140-2-39-1 Flange Yoke SPL140 Series
|
|
Your Cost
$220.95
Sorry, sold out
STATUS:
FACTORY BACK ORDER at this time
|
|
DANA SPICER 140-2-39-1
SPL140 Series Flange Yoke
UPC: 023913325633
Part Number: 140-2-39-1
|
DANA SPICER 140-2-39-1 Flange Yoke SPL140 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY BACK ORDER at this time
YOUR COST:
$220.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 140-2-39-1
SPL140 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.381 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 6.437 inches
- Series = SPL140
- U-Joint Width = 5.028 inches
- D - U-Joint Bearing cap diameter = 1.937 inches
- G - Center of u-joint bore to Face of flange = 2.952 inches
- Special Notes: 1/2 ROUND PART WITH SPECIAL GMC BOLT HOLE SIZE
|
|
DANA SPICER 140-2-39-1 Flange Yoke SPL140 Series
|
|
