Dana Spicer 4-2-1069 Flange Yoke 1550 Series
|
|
Your Cost
$92.48
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 4-2-1069
1550 Series Flange Yoke
- A - Flange or Swing Diameter = 5.906 inches
- B - Bolt Circle Diameter = 5.125 inches
- Bolt Hole Diameter = 0.484 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 3.547 inches
- Series = 1550
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.964 inches
- D - U-Joint Bearing cap diameter = 1.375 inches
- G - Center of u-joint bore to Face of flange = 3.156 inches
- Design = Rectangular
- Special Notes: Use with Dana Spicer 5-155X, 5-808X or 5-809X
UPC: 023913700577
Part Number: 4-2-1069
|
Dana Spicer 4-2-1069 Flange Yoke 1550 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$92.48
|
DANA SPICER 4-2-1069
1550 Series Flange Yoke
- A - Flange or Swing Diameter = 5.906 inches
- B - Bolt Circle Diameter = 5.125 inches
- Bolt Hole Diameter = 0.484 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 3.547 inches
- Series = 1550
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.964 inches
- D - U-Joint Bearing cap diameter = 1.375 inches
- G - Center of u-joint bore to Face of flange = 3.156 inches
- Design = Rectangular
- Special Notes: Use with Dana Spicer 5-155X, 5-808X or 5-809X
|
|
Dana Spicer 4-2-1069 Flange Yoke 1550 Series
|
|
