Dana Spicer 212019X CV Centering Yoke Double Cardan 1350 series fits N3-4-JL-TCF transfer case yoke

Part Number:
212019X

UPC:

023913235437

Your Cost ~~$120.95~~ Sale Price $105.95

You Save $15.00

STATUS: IN STOCK - FREE SHIPPING

DANA SPICER 212019X

1350 Series Double Cardan Centering Yoke

Non Greaseable

Fits Neapco N3-4-JL-TCF

Dana Spicer 212019X CV Centering Yoke Double Cardan 1350 series fits N3-4-JL-TCF transfer case yoke

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: ~~$120.95~~ Sale Price $105.95

You Save $15.00

DANA SPICER 212019X

1350 Series Double Cardan Centering Yoke

Non Greaseable

Fits Neapco N3-4-JL-TCF
Fits Spicer 10049139

DIMENSIONS

Fits 1350 U-Joint
- (3.625 inches) 3-5/8 inches between locating tabs on centering yoke
- (1.187 inches) 1-3/16 inch dimension of saddle to hold U-Joint Bearing cap
Bolt Holes are 5/16 - 24 fine thread
- Bolt hole spacing 1.62 inches across u-joint cap
- Bolt hole spacing 2.75 inches side to side
Fits .500 inch stud diameter

INCLUDES

New spring Included

When out of stock NEAPCO N3-83-019X centering yoke can be used

It is recommended that you install a new rubber boot every time you service the Double Cardan CV joint.

Please see the bottom of this page for new rubber boot

PLEASE NOTE: This part is not interchangeable with the geaseable centering yoke version. You cannot put this NON Greaseable centering yoke onto a shaft that was originally built for the greaseable centering yoke. The socket diameter is larger and will restrict the movement of the Double Cardan CV Joint.

Dana Spicer 212019X CV Centering Yoke Double Cardan 1350 series fits N3-4-JL-TCF transfer case yoke
