Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

DANA SPICER 708064 Complete LEFT SIDE Axle Assembly with 32 SPLINE Inner fits 2000, 2001, 2002 DODGE Ram 2500HD and Ram 3500 with DANA 60 DISCONNECT Front Axle - FREE SHIPPING
Part Number:
708064


UPC:
023913134754
Your Cost $485.95
STATUS:  SOLD OUT...More Coming Soon

DANA SPICER 708064

Complete LEFT Front Axle Assembly fits Drivers Side

  • Fits 2000, 2001, 2002 Dodge RAM 2500HD and 3500 4x4 with DANA 60 DISCONNECT FRONT AXLE
  • 32 spline inner
Spicer
DANA SPICER 708064 Complete LEFT SIDE Axle Assembly with 32 SPLINE Inner fits 2000, 2001, 2002 DODGE Ram 2500HD and Ram 3500 with DANA 60 DISCONNECT Front Axle - FREE SHIPPING
DANA SPICER 708064 Fits Dodge with DANA 60 Disconnect Front
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  SOLD OUT...More Coming Soon
YOUR COST:  $485.95
This item qualifies for FREE GROUND SHIPPING to the lower 48 states

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SPICER 708064

Complete LEFT Front Axle Assembly fits Drivers Side

  • Fits 2000, 2001, 2002 Dodge RAM 2500HD and 3500 4x4 with DANA 60 DISCONNECT FRONT AXLE
  • 32 spline inner

INCLUDES:

  • (1) 80375 OUTER axle shaft with dust shield
  • (1) 80178-1 INNER axle shaft
  • (1) SPL55-3X UNIVERSAL JOINT
  • Fully Assembled and ready to install.

DIMENSIONS:

  • Dimension "A" = 26.52 inches
  • Dimension "B" = 7.39
  • Dimension "B1" = 1.41 inch diameter with 33 splines
  • Dimension "C1" = 1.37 inch diameter with 32 Splines
  • Dimension "C" = 19.13 inches
  • U-Joint Snap Ring Dimension = 3 inches
  • U-Joint Bearing Cap Diameter = 1.375 inches ( 1 3/8 inches )
image/jpeg
DANA SPICER 708064 Complete LEFT SIDE Axle Assembly with 32 SPLINE Inner fits 2000, 2001, 2002 DODGE Ram 2500HD and Ram 3500 with DANA 60 DISCONNECT Front Axle - FREE SHIPPING

DANA SPICER 708064 Fits Dodge with DANA 60 Disconnect Front

Click to Load this Photo
Click Here to Enlarge
Click to Load this Photo
Click Here to Enlarge
