DANA SPICER 250-2-15 Serrated Flange Yoke SPL250 Series
|
|
Your Cost
$210.95
STATUS:
FACTORY DIRECT - SPECIAL ORDER
|
|
DANA SPICER 250-2-15
SPL250 Series Serrated Flange Yoke
UPC: 023913247379
Part Number: 250-2-15
|
DANA SPICER 250-2-15 Serrated Flange Yoke SPL250 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT - SPECIAL ORDER
YOUR COST:
$210.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 250-2-15
SPL250 Series Serrated Flange Yoke
- A - Flange or Swing Diameter = 7.087 inches
- B - Bolt Circle Diameter = 5.906 inches
- Bolt Hole Diameter = 0.594 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter
- Series = SPL250
- U-Joint Width = 5.986 inches
- D - U-Joint Bearing cap diameter = 2.362 inches
- G - Center of u-joint bore to Face of flange = 3.583 inches
- Special Notes: 180 mm flange with serrated flange face
|
|
DANA SPICER 250-2-15 Serrated Flange Yoke SPL250 Series
|
|
