DANA SPICER 6.3-2-19 Flange Yoke 1760 Series
Part Number:
6.3-2-19


UPC:
023913215132
Your Cost $273.95
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 6.3-2-19

1760 Series Flange Yoke




Spicer
DANA SPICER 6.3-2-19 Flange Yoke 1760 Series
DANA SPICER 6.3-2-19 Flange Yoke 1760 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $273.95

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 6.3-2-19

1760 Series Flange Yoke

  • A - Flange or Swing Diameter = 8 inches
  • B - Bolt Circle Diameter = 7.250 inches
    • Bolt Hole Diameter = 0.438 inches
    • Bolt Holes = 12
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 7.750 inches
    • Center Pilot = MALE
  • Series = 1760
    • U-Joint Width = 7 inches
    • D - U-Joint Bearing cap diameter = 1.938 inches
  • G - Center of u-joint bore to Face of flange = 3.375 inches
  • Special Notes:





Heavy duty truck and equipment driveshaft flange yokes at Denny's Driveshafts

DANA SPICER 6.3-2-19 Flange Yoke 1760 Series

DANA SPICER 6.3-2-19 Flange Yoke 1760 Series
