DANA SPICER 6-2-14898 Flange Yoke 1710 Series Bearing Strap Half Round Style
|
|
Your Cost
$153.62
Sorry, sold out
STATUS:
Discontinued Item...See other choices listed
|
|
DANA SPICER 6-2-14898
1710 Series Flange Yoke
THIS PART IS OBSOLETE AND NO LONGER AVAILABLE
UPC:
Part Number: 6-2-14898
|
NOT ACTUAL PART - Representative image of bearing strap half round style flange yoke
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: Discontinued Item...See other choices listed
YOUR COST:
$153.62
|
DANA SPICER 6-2-14898
1710 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.396 inches
- Bolt Holes = 12
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Series = 1710
- U-Joint Width = 6.094 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3 inches
- Special Notes: Bearing Strap Half Round Style ...10 mm bolt holes, equally spaced
|
|
NOT ACTUAL PART - Representative image of bearing strap half round style flange yoke
|
|
