Dana Spicer 2-3-14191X Slip Yoke 1330 Series fits Dodge 1996 to 1998 NP231D transfer case

Part Number:
2-3-14191X

UPC:

023913233785

Your Cost ~~$118.48~~ Sale Price $99.23

You Save $19.25

STATUS: IN STOCK

DANA SPICER 2-3-14191X

1330 Series Transfer case slip yoke

Fits some 1996 to 1998 Dodge NP231D Transfer case
You MUST measure barrel diameter before buying. Be sure that Dimension "R" is 1.558 inches
- NOTE: This usually requires a 1330 to 7290 combination u-joint when connecting this outside snap ring style slip yoke to a stock inside "C" clip style driveshaft
- NOTE: This slip yoke DOES NOT FIT any 27 spline GM transmissions

Dana Spicer 2-3-14191X Slip Yoke 1330 Series fits Dodge 1996 to 1998 NP231D transfer case

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: ~~$118.48~~ Sale Price $99.23

You Save $19.25

DANA SPICER 2-3-14191X

1330 Series Transfer case slip yoke

Fits some 1996 to 1998 Dodge NP231D Transfer case
You MUST measure barrel diameter before buying. Be sure that Dimension "R" is 1.558 inches
- NOTE: This usually requires a 1330 to 7290 combination u-joint when connecting this outside snap ring style slip yoke to a stock inside "C" clip style driveshaft
- NOTE: This slip yoke DOES NOT FIT any 27 spline GM transmissions

Spline/Hole Outside Diameter = 1.176
Number of Splines = 26/27
- this slip yoke will have 26 internal splines and 1 wide space
- transfer case output shaft will have 27 splines
Series = 1330
Lock up style = OUTSIDE SNAP Ring
Universal Joint Width = 3.625
D - Universal Joint Bore = 1.062
J - Center of u-joint bore to End of Slip yoke = 7.290
R - Barrel Outside Diameter = 1.558

CLICK HERE : For ALL DANA SPICER Slip Yoke Part Numbers, Specifications and Dimensions
