DANA SPICER 2-3-5821X Slip Yoke 1310 Series 1.375 - 16 spline threaded style for screw on dust seal

Part Number:
2-3-5821X

UPC:

023913236120

Your Cost ~~$142.42~~ Sale Price $119.27

You Save $23.15

STATUS: IN STOCK

DANA SPICER 2-3-5821X

1310 Series Slip Yoke

DANA SPICER 2-3-5821X Slip Yoke 1310 Series threaded style for screw on dust seal

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: ~~$142.42~~ Sale Price $119.27

You Save $23.15

DANA SPICER 2-3-5821X

1310 Series Slip Yoke

Spline/Hole Outside Diameter = 1.375
Number of Splines = 16
Series = 1310
Lock up style = OUTSIDE
Universal Joint Width = 3.219
D - Universal Joint Bore = 1.062
- Dust Cap Style = THREADED FOR SCREW ON DUST CAP
F - Center of u-joint bore to plug = 1.500
J - Center of u-joint bore to End of Slip yoke = 7.875

Special Notes:
- Use dust cap kit D3E with splined seal for reverse slip applications with full length spline...see listing below
- Use dust cap kit D2C with full contact seal for splines with smooth skank...see listing below
- For same slip yoke as 2-3-5821X but 1 inch shorter see 2-3-5221X
- For same slip yoke as 2-3-5821X with press on seal see 2-3-8021KX

CLICK HERE : For ALL DANA SPICER Slip Yoke Part Numbers, Specifications and Dimensions

DANA SPICER 2-3-5821X Slip Yoke 1310 Series threaded style for screw on dust seal

You May Also Need These Parts to Complete the Job

Dana Spicer 5-153X Universal Joint Greaseable 1310 series 3.219 x 1.062 outside snap rings Part#: 5-153X $13.10	Dana Spicer D3E Slip Yoke Dust Cap 1.375-16 SPLINED CORK SEAL 1.652 ID thread diameter SPLINED ID Part#: D3E $17.88
Dana Spicer D2C Slip Yoke Dust Cap for 1.375 inch spline 1.652 ID thread diameter CORK SEAL with ROUND ID Part#: D2C $17.95	Dana Spicer 5-1310-1X Universal Joint 1310 Series GREASEABLE 3.219 x 1.062 outside snap rings Part#: 5-1310-1X $26.95
Dana Spicer 5-1310X Universal Joint 1310 Series NON Greaseable 3.219 x 1.062 outside snap rings Part#: 5-1310X $19.66	Neapco 1-0153 Greaseable universal joint 1310 series 3.219 x 1.062 outside snap rings Part#: 1-0153 $15.76
